1500kg Telescopic Loader
Recommended application
The HY1500 telescopic loader has the rated load weight of 1500kg, the unloading height up to 41m, and the turning angle at about 27°. Therefore, with flexible operation and various functions, a machine can replace at least 20 workers’ labor, which is widely used in farm, ranch, logistics warehouse, municipal maintenance and other work site.
The loader is equipped with front standard bucket and fast connector, enabling the users easily replace attachments with different functions according to the different operating requirements.
Basic parameters| Overall weight(kg) | 4000 |
| L×w×h(mm) | 4320×1870×2720 |
| Rated bucket capacity(m3) | 0.7 |
| Rated load(kg) | 1500 |
| Maximum lifting height (mm) | 4100 |
| Bucket indicator | Yes |
| Max. Breakout force(kn) | 43 |
| Engine | Model | Xinchai 498BT(EURO III) |
| Type | In-line arrangement, Water cooling, four-stroke | |
| Rated power(kw) | 36.8kw | |
| Rated speed(r/min) | 2200 | |
| Transmission system | Model of torque converter | YJ240 |
| Type | single-phase single-stage radial-inward turbine triplex | |
| Gearbox type | Fixed-spindle power shift | |
| Gear shift | 2 gears ahead,2 gear astern | |
| Hydraulic system | Distribution of work valve | ZL20B |
| Working pump | CBGj1045,CBGq1018 | |
| Steering system | Type | Articulated hydraulic steering |
| Max. turning angle | 27±1° | |
| Min turning radius(mm) | 3000 | |
| Brake system | Brake type | Oil brake(Vacuum booster) |
| Tyres | Standard tyres | 14-17.5 |
| Optional wide tyres | 20.5-16, 20.5/70-16,23.5/70-16 |
1. The Perkins brand of 404D-22 engine, cooperated with the 220V engine heater, runs steadily.
2. The loader adopts four wheel drive and 12-16.5 vacuum tires, adapted to various working conditions.
3. The cab with deluxe seats is equipped with LED lights, adjustable steering wheel, hydraulic joystick and microcomputer controlled operating system, making it easy for the drivers to operate.
Hongyuan Vehicle has been manufacturing super quality wheel loaders, is offering front end loaders for agricultural and heavy construction industry. By changing the associated implements on the loaders, we can offer a wide range of special purpose loaders, like sugar cane grab loader, log grapple loader, rough terrain forklift truck, snow plow, rock breaker and so on. With rich export experience and quality assurance, we provide custom need farming and construction equipment with competitive prices.
